NetApp HCI
Your Bridge to the Next-Generation Data Center
Transform your IT infrastructure with the enterprise-scale hyper converged infrastructure solution from NetApp. Run multiple applications with guaranteed performance to confidently deploy NetApp HCI across your entire data center.
NetApp HCI named an Evolutionary Disruptor by Gartner
See how NetApp HCI compares.
Read the latest report, Gartner’s Competitive Landscape: Hyperconverged Integrated Systems.
Take the Pain Out of Deploying Infrastructure
NetApp has refined all installation and management processes, making NetApp HCI easy to set up and configure. You won’t need a team of IT experts to deploy.
Accelerating Customer Growth with HCI as a Service
Australia-based Consultel Cloud leverages NetApp HCI to shatter expectations of cloud economics and accelerate customers’ ability to expand into new business opportunities. As the first of its kind to have an HCI as a service offering, Consultel delivers unmatched scalability and cloud choice to customers.
Take simple to a whole new level
Take the burden off your busy IT staff. Let NetApp Services efficiently install, configure, integrate, and manage your NetApp HCI solution.
Primary Use Cases
Private Cloud
Accelerate delivery of your private cloud services with an enterprise-scale hyperconverged infrastructure
End-User Computing
Accelerate deployment, increase user satisfaction and simplify scaling with NetApp HCI and VMware Horizon.
Workload Consolidation
Eliminate silo’s with a hyperconverged infrastructure that lets you predictably run multiple applications
Complete HCI Architecture Comparison Guide.
Today’s HCI platforms are mostly built on three common architectures. Find out which one is right for your business.
Models & Specs
Node types and sizes can be mixed and matched based on best practices
Minimum configuration (4 RU): 2 Chassis with 2 Compute, 4 Storage Nodes and 2 Expansion Slots
Memory384 GB512 GB768 GBOperating Shock20 G, 2.5ms, half-sine, one shock on each side
 |
|
|
|
|---|---|---|---|
| Small | Medium | Large | |
| Storage Node | H300S | H500S | H700S |
| Rack Units | 1 RU, half-width | ||
| SSD | 6 x 480 GB | 6 x 960 GB Encrypting/Non-Encrypting | 6 x 1.92 TB |
| Effective Block Capacity[1] | 5.5TB – 11 TB | 11TB – 22 TB | 22TB – 44 TB |
| Performance per node | 50,000 IOPS | 50,000 IOPS | 100,000 IOPS |
| Storage OS | NetApp SolidFire Element OS 10.0 | ||
| Base Networking | 2 x 10/25 GbE (SFP 28) [2] 2 x 1 GbE RJ45 |
||
| Optional out-of-band management | 1 x 1 GbE RJ45 | ||
| Compute Node | H300E | H500E | H700E |
| Rack Units | 1 RU, half-width | ||
| CPU | 2 x Intel E5-2620v4, 8 cores, 2.1 GHz | 2 x Intel E5-2650v4, 12 cores, 2.2 GHz | 2 x Intel E5-2695v4, 18 cores, 2.1 GHz |
| Cores for VM’s | 16 | 24 | 36 |
| Hypervisor | VMware vSphere 6.0, 6.5 | ||
| Base Networking | 4 x 10/25 GbE (SFP 28)[2] 2 x 1 GbE RJ45 |
||
| Optional out-of-band management | 1 x 1 GbE RJ45 | ||
| Rack Units | 2 RU | ||
| HCI nodes | 1 RU, half-width – Mix and match four HCI nodes per chassis | ||
| Power Input | 110V AC or 220V AC 1+1 redundant |
240V AC 1+1 redundant |
240V 1+1 redundant |
| Max Watts/Current Per Power Supply | 1100W/110V/10A | 2200W/240V/12-11A | 2200W/240V/12-11A |
| Node Physical Dimensions | 39.20 mm / 1.54 in H
39.20 mm / 1.54 in H 196.25 mm / 7.73 in W 587.55 mm / 23.13 in D ~ 3.60 kg / 8.0 lbs |
||
| Chassis Physical Dimensions | 8.80 cm / 3.46 in H
8.80 cm / 3.46 in H 44.70 cm / 17.60 in W 73.00 cm / 28.74 in D ~ 24.70 kg / 54.45 lbs |
||
| Operating temperature, altitude, and relative humidity | 10° C to 35° C (50° F to 95° F); at <= 914.40m (at <= 3,000ft) elevation; 1° C derating per 1,000ft;
8% to 90% relative humidity, noncondensing |
||
| Nonoperating temperature | -40° C to 70° C (-40° F to 158° F) | ||
| Operating Vibration | 0.4 GRMS, Random 5 – 200 Hz (60 min/axis); 0.25 G, Sine 5 – 200 Hz (15 min/axis) | ||
| Non-operating Vibration | 0.98 GRMS, Random 5 – 500Hz (30 min/axis); 0.5 G, Sine 5 – 200 Hz (15 min/axis) | ||
| Non-operating Shock | 20 G, 10ms, square wave, one shock on each side | ||
| Heat Dissipation | Typical BTU/hr — Small 2,730; Medium 3,412; Large 4,129
Worst Case BTU/hr — Small 3,856; Medium 4,982; Large 6,142 |
||
| Certifications | FCC, UL, IEC 60950-1, CE, VCCI, KCC, SABS LOA (South Africa),
BSMI, SONCAP, KEBS, KSA, TBS, UNGS, FIPS 140-2*** |
||
